Altronix eFlow104NA8 Series Installation Manual page 2

Altronix eFlow104NKA8 and eFlow104NKA8D distribute and switch power to access control systems and accesso-
ries. They convert a 120VAC 60Hz input into eight (8) independently controlled 12VDC or 24VDC protected outputs.
Access Power Controller's dual input design allows power to be steered from two (2) factory installed independent
low voltage 12 or 24VDC Altronix power supplies to eight (8) independently controlled fuse (eFlow104NKA8) or
PTC (eFlow104NKA8D) protected outputs. Power outputs can be converted to dry form "C" contacts. Outputs are
activated by an open collector sink, normally open (NO), normally closed (NC) dry trigger input, or wet output from
an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. eFlow104NKA8(D) will route power to
a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door Holders, etc.
Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The FACP Interface enables Emergency Egress,
Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually
selectable for any or all of the eight (8) outputs. The spade connectors allow you to daisy chain power to multiple
ACMS8(CB) modules. This feature allows you to distribute the power over more outputs for larger systems.
Battery
7AH
12AH
40AH
65AH
- 2 -
Overview:
Stand-by Specifications:
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
0.4A/10A
1A/10A
6A/10A
6A/10A
Fire Applications
24 hr. Stand-by/
5 min. Alarm
N/A
0.3A/10A
1.2A/10A
1.5A/10A
eFlow104NKA8(D) Installation Guide
Access Control
Applications
Stand-by
5 Mins./10A
15 Mins./10A
Over 2 Hours/10A
Over 4 Hours/10A
