5 - Power output connection from Power Unit - Connecting Cables - :
Locate the connection points in the Power Unit.
Ethernet connection
1
1
Control supply to Dispenser
2
2
P P
L L
N N
E E
47
CIRCONTROL — Raption HPC Installation Manual
