B) Overview Of Dispenser - Circontrol Raption HPC Installation Manual

B)
Overview of Dispenser
1
2
3
4
5
1 - Cover
5 - Coolant area
9 - Emergency
button
13 - Front door
Note: Depending on the model, the components can vary.
6
7
8
9
10
2 - Courtesy Lights
6 - LED beacon light
10 - Key lock access
front door cooling area
11
3 - Screen
7 - Locking handle
11 - Key lock access rear
door cooling area
12
13
4 - RFID Reader
8 - CCS plug
12 - Antenna
10
