4 - Power input connection for the Power Unit
- Connecting control supply cables - :
Orange cables are
powered although
disconnector switch
is turned off.
P P
N N L L
E E
Note: The control part is separated from the power part.
This is why can be presence of voltage even after being disconnected.
46
