B)
Minimum distances of Power Unit
Notes:
- Respect the minimum frontal and rear distance to allow proper circulation of air flow.
This unit has forced ventilation.
- If Bollard Impact Protector is installed, keep 800 mm as a minimum distance in order
to give enough space to open the frontal door of the Charge Point for maintenance
tasks.
800
800
Units specified in millimetres
22
