Adjusting Steering Wheel

• After adjusting the steering wheel, try moving the steering wheel back and forth
and up and down to make sure it is securely locked in its position.
Steering Wheel
Tilt Lever
5347M-0401-030E
Fixing Pin
5355M-5363-0401-040
Operation
2.
3.
Fuel Filelr Cap
NOTE
Adjusting Angle (Tilting)
1.
2.
3.
Steering Column
Open the fuel filler cap and fill fuel.
Put the fuel filler cap back in place and close
it securely.
• Fuel : Automotive Unleaded Gasoline
• Fuel Tank Capacity : 20L
Pull up the tilt lever to adjust the steering
wheel angle.
There are five positions for the steering
wheel angle.
After adjusting steering angle, return the tilt
lever to lock the steering wheel securely.
Adjusting Height
1. Remove fixing pin from the steering column.
-18-
