CanyCom Masao CMX2302 Operator's Manual page 23

Ride-on brushcutter
Table of Contents

Advertisement

Controls and Components
1 Main Switch . . . . . . . . . . . . . Main switch is used to start or stop the engine.
2 Choke Knob . . . . . . . . . . . . . Choke Knob is used to help start the engine by closing the
3 Throttle Lever . . . . . . . . . . . Throttle lever is used to control the engine speed.
4 Drive Pedal . . . . . . . . . . . . . . Drive pedal is used to control the traveling direction and
5 Drive Lever . . . . . . . . . . . . . . Drive lever is used to control the traveling direction and
6 Parking Brake Pedal . . . . . . Parking Brake pedal is used to keep the machine from
7 Parking Brake Lock . . . . . . . Parking brake lock lever is used when parking the machine
Lever
8 Auxiliary Transmission . . . . Auxiliary transmission shift lever is used to shift the
Shift Lever
9 2WD/AWD Shift Lever . . . . . 2WD/AWD shift lever is used to switch between the 2WD
10 Differential Lock Lever . . . . Differential lock lever is used to lock the differential when
choke valve.
speed of the machine. The machine moves forward when
the front of the drive pedal is depressed and backward
when the rear of the drive pedal is depressed. The angle
of the drive pedal determines the speed.
speed of the machine. The machine moves forward when
the lever is tilted forward and backward when the lever is
tilted backward. The angle of the drive lever determines
the speed.
moving. When the parking brake pedal is depressed, the
drive lever returns to the neutral position and the parking
brake is engaged.
securely. Pulling the parking brake lock lever while the
parking brake pedal is depressed locks the parking brake
pedalin the engaged position.
auxiliary transmission to change the speed of the machine.
(rear-wheel drive) and AWD (all-wheel drive) modes.
the rear tires slip. Tilting the differential lock lever to [ON]
position locks the differential.
-13-
