Shifting - CanyCom Masao CMX2302 Operator's Manual

Parking Brake Pedal
5347M-0402-121E

Shifting

• Always shift gears firmly. When the transmission is not firmly shifted, it may
jump out of the gear, resulting in loss of control of the machine.
• Always stop the machine to shift gears. Shifting gears while the machine is in
motion can damage the transmission.
• Use [L] (low speed) mode when cutting (mowing). Cutting in [H] (high speed)
mode can put excessive strain and damage the cutting mechanism.
Auxiliary
Transmission
Shift Lever
5347M-0402-102E
Operation
3. Depress the parking brake pedal to stop the
machine completely.
NOTE
• When the parking brake pedal is depressed,
the drive lever returns to the neutral
position.
1. Stop the machine.
2. Move the auxiliary transmission shift lever to [H]
(high speed) or [L] (low speed) position firmly.
L
N
NOTE
H
• See Specifications (page 15) for the speed
range in either gear position.
-31-
