1
TOP TUBE
16
CHAIN
2
DOWN TUBE
17
CHAINRING
3
SEAT TUBE
18
CHAIN GUIDE
4
HEAD TUBE
19
CRANK ARM
5
CHAINSTAY
20
PEDAL
6
CHAINSTAY PROTECTOR
21
MOTOR
7
SEAT STAY
22
HANDLEBAR
8
FORK
23
SHIFTER
9
SADDLE
24
BRAKE LEVER
10
SEATPOST
25
REMOTE
11
SEATPOST CLAMP
26
TCU / MASTERMIND TCU*
12
REAR SHOCK
27
STEM
13
CASSETTE
28
ADJUSTABLE HEADSET*
14
DERAILLEUR HANGER
29
INTERNAL BATTERY
15
REAR DERAILLEUR
30
CHARGING SOCKET
* Not all models are equipped with all the above components.
TURBO CONNECT UNIT (TCU)
31
FRONT BRAKE CALIPER
Fig. 2.2
Some Levo models are equipped with the
32
FRONT BRAKE ROTOR
TCU display. The display turns on the motor,
and provides access to the support modes
33
REAR BRAKE CALIPER
options, battery charge level and error codes.
34
REAR BRAKE ROTOR
35
SPOKE
36
RIM
37
TIRE
38
VALVE
39
HUB
MASTERMIND TURBO CONNECT
UNIT(MM TCU)
40
THRU-AXLE
Fig. 2.3
Some Levo models are equipped with the
41
WATERBOTTLE CAGE
MasterMind TCU display. The display turns
on the motor, and provides a visual on the
42
SWAT TOOL*
display for Speed, Battery charge level, Mode,
Heart Rate, Error Codes, Distance Ridden,
ADJUSTABLE HORST
43
Elevation, Rider Power, Odometer, Time
PIVOT
Ridden, and Time of Day.
2.2
2.3
4
