8. SYSTEM INTE RFACE
Depending on the model, your Levo is equipped with either the TCU or MasterMind TCU display.
The functionality of the system interface summarized in this manual is current
as of the date this manual was written and is subject to change. Specialized
reserves the right to change the functionality at any time and without notice,
including modifying, reducing, and/or adding features.
WARNING! Use caution when viewing or using the display while riding, as it
can be distracting and can lead to accidents. You should always stop before
changing settings or operating the various functions of the display. Do not
attempt to customize the pages or perform setup adjustments while riding.
8 .1. TC U
8.1
MODE BUTTON
BATTERY LEVEL
ERROR CODES
POWER
ON/OFF
Fig. 8.1
Some Levo models are equipped with the TCU display. The TCU turns on the system and
provides access to the support modes options, battery charge level, and error codes.
The six-digit BLE code for Bluetooth pairing is found underneath the TCU on the top tube,
as well as on the removable yellow sticker, see section 5.4.
The USB port on the underside of the display is for Specialized retailers and service
centers. Make sure the rubber door is sealed at all times while riding.
8.2. M A ST ER M I ND TC U
8.2
USB BATTERY
DOOR
BLE PAIRING
CODE
Fig. 8.2
Some Levo models are equipped with the MasterMind TCU display. The MasterMind TCU
turns on the system and provides information on the display.
The MasterMind TCU has customizable screens that show options such as speed, battery
charge level, mode, heart rate, and more.
The type C USB port on the underside of the display is for Specialized retailers and service
centers.
DISPLAY
POWER
ON/OFF
TYPE C USB
DOOR
