10 . 9. CH A RG E R T EC HN I C AL DATA
CHARGER MODEL
UNIT
NUMBER
°C
STORAGE
TEMPERATURE
°F
OPERATING VOLTAGE
V
AC INPUT VOLTAGE
V
FREQUENCY
Hz
MAX CHARGE CURRENT
A
DIMENSIONS
mm
The range of the battery can vary considerably depending on the model/capacity of the battery
and riding conditions, such as the gradient of your route and the support mode.
10.11
WARNING! Before use, read and familiarize yourself with the information on
the battery and charger labels (Fig. 10.11).
35
SPECIFICATION
SBC-C04
SBC-C05
Not in the scope of UL 2849 approval
-20 — +60
-20 — +60
-4 — +140
-4 — +140
42
42
100 — 240
100 — 240
50 / 60
50 / 60
4
2
178 X 80 X 37
147 X 65.5 X 34
1 1. S PECIFICAT IO NS
11.1. G ENERA L SPECIF IC AT IONS
ITEM
SBC-C07
HEADSET
-20 — +60
HEADSET CUPS
-4 — +140
42
SEAT COLLAR
230 — 240
SEAT COLLAR DIAMETER
50 / 60
SEATPOST DIAMETER
4
DERAILLEUR HANGER
179 X 86 X 50.5
REAR HUB AXLE
REAR TIRE MAX
REAR WHEEL TRAVEL
SHOCK LENGTH / STROKE
SHOCK SAG
SHOCK MOUNT HARDWARE
MAX FORK TRAVEL
MIN / MAX CHAINRING
MIN / MAX REAR BRAKE
ROTOR
CAUTION: Certain chainrings may not have adequate clearance with the
chainstay. Verify spacing and chainline before using it.
PART #
SPECIFICATION
HDS NO.42/ACB/S/F/N 46CONE SPACER,AL
S182500005
COMPRS RING,UP1.125/LOW1.5 CRMO 45,AL
CROWN RACE,ANO MATT BLK
S212500015
HDS MY22 LEVO HEADSET CUPS
STC KCNC, SPL-SC02-386, EXTRUDED, 7075-
S184700004
T6, 38.6MM, SCM435, NONE FINISH BOLT,
BOLT CLAMP TYPE
38.6 mm
34.9 mm
HGR SRAM AC UDH DERAILLEUR HANGER AL
S202600002
BLACK
AXL THROUGH AXLE, JD JD-QR43, 7075-T73
S170200003
AXLE W/C6801 WASHER, REAR, 148MM SPAC-
ING, 172MM LENGTH, 12MM
27.5 x 2.6
150 mm
210 mm / 55 mm
13.75 mm (25%)
8 mm ID x 20 mm W (front) / direct mount rear
150 mm (S1), 160 mm (S2-S6)
32-34t
180 mm / 220 mm
