1 3. 3 . ADJU ST I N G C O M PRES S ION
Compression damping (blue knob) controls the amount of support of the shock platform, in
other words, the shock's ability to resist low-speed pedaling forces while still being able to
absorb high-speed compression forces.
Please refer to the suspension manual for specifics about the compression options provided
by your suspension. Typically, a suspension is equipped with some or all of the following
settings:
OPEN: Low-speed compression setting optimized for the perfect balance of control and
plushness for steep, aggressive descents.
PEDAL (certain models): Moderate low-speed compression setting is activated for an
optimal blend of pedaling efficiency and bicycle control on variable terrain.
LOCK: The firmest low-speed compression setting is activated for maximum pedaling
efficiency.
47
14. DERAILLEUR HANGE R
WARNING! Correct grease application is critical to rider safety. ONLY apply
grease as instructed.
INSTALLATION PROCEDURE:
14.1
Fig. 14.1
Install the UDH hanger assembly into the frame dropout.
Fig. 14.2
Rotate the UDH hanger forward until it is completely seated in the hanger pocket or
contacts the rotational stop tab.
Apply grease ONLY to the thru-axle threads. Do NOT apply grease to the
frame, UDH hanger, or UDH bolt threads.
The hanger must be completely seated in the hanger pocket or against the
frame stop tab when tightened to the specified torque.
14.2
