8 . 9. CH ANG IN G SUP PO RT M OD ES ( TCU)
8.9
Fig. 8.9
The support modes are displayed around the S-button (mode). Pressing the S-button
„
cycles through the modes.
The modes will cycle through the three main support modes, starting at TRAIL (default).
„
OFF MODE is activated by a long press of the S-button (MODE).
On the remote the (+) button increases the amount of support and the (-) button
„
decreases the amount of support.
TURBO
Bluetooth
TRAIL
SMART
CONTROL
+
ECO
2
SEC
OFF
TURBO
Bluetooth
TRAIL
SMART
CONTROL
ECO
OFF
INFO: On the remote, after reaching the strongest or weakest mode, the
system will not continue to switch. To reduce from TURBO to TRAIL to ECO to
OFF, you have to press the (-) button. To increase from OFF to ECO to TRAIL
to TURBO, you have to press the (+) button.
8.1 0. CH ANG I NG SU PPO RT M OD ES (M A ST ER M I ND TC U )
8.10
TURBO
TRAIL
ECO
OFF
SMART
WALK
Fig. 8.10 (MasterMind TCU Only)
As a quick reference, each mode is associated with a color. When you change modes, the
„
color on the display changes.
On the remote, the (+) button increases the amount of support and the (-) button
„
decreases the amount of support.
Modes cannot be changed directly on the MasterMind TCU, all interactions
other than powering the bicycle on and off are performed with the remote.
TURBO TRAIL ECO
OFF SMART WALK
