8 .1 3 . C U STOM IZ ING T HE M A STE R MIN D TCU D ISPLAY
The MasterMind TCU is shipped with multiple standard screen configurations. With the
Specialized app you can add more screens, customize the layouts, rename them and change
the stats displayed.
8.13
Fig. 8.13
The MasterMind TCU has multiple customizable pages with various layouts and data fields,
which can be set up according to your preference.
To navigate the pages, use the remote (F1) button to scroll through the pages.
Layouts and pages are only customizable in the Specialized app.
For more information, visit Specialized support center at
specialized.com.
8.14 . CO NNECTI V I TY O PT I ONS
The Turbo Technology System provides a high degree of interface flexibility through Bluetooth
and/or ANT+ connectivity.
BLUETOOTH LOW ENERGY (BLE)
BLE is used for connecting to the bicycle to the Specialized app.
ANT+
ANT+ can be used to connect to the sensors for Speed, Rider Power, and Cadence. The
sensor data can be received via the ANT+ module built into the TCU.
In your ANT+ device, search for those sensors and connect to them.
Some bicycle-specific ANT+ devices feature so-called "LEV" data fields you can use to see
all available e-bike data.
8.1 5 . E R RO R CO D ES ( TC U )
The Levo is equipped with a built-in diagnostic system to automatically check and identify the
functionality of the system. If the system detects an error, the TCU display will alert the user
with an error code of red and blue LEDs, as shown in Fig. 8.14.
If you receive such an error, please restart the system. If the error message continues
to display, please contact your Authorized Specialized Retailer for further instructions.
Depending on the type of error message, the system may be switched off automatically. In
any case, the bicycle can be ridden without motor support, with the system turned off.
The Specialized app supports the rider with user actions for errors and
diagnostic reports which can be shared with retailers who can give further
advice based on the bicycle serial number.
www.support.
22
