Fault Codes And Alarms - WaterLogic WL3FW FIREWALL Manual

WL3FW provides user reassurance of key functional elements with 4 lights illuminate green to indicate
total purification security.
All Status Indicator Lights Off
No power to unit or front PCB. Ensure power supply and red power switch is on. See Troubleshooting
for further instructions.
Firewall Purification Light Out and 20 Second Audible Alarm
Firewall UV Active
Firewall UV System is inactive. See Troubleshooting for further instructions.
WL3 FW Manual
WL3FW FAULT CODES AND ALARMS
Power Light – Indicates ON/OFF Status.
Light flashes with audible alarm when leak detected.
Filtration Light – Indicates Filtration Present.
No filter timer or flow-counter function.
Firewall Purification Light – Indicates Firewall Status.
Firewall UV is active with green lit and inactive when off.
BioCote® Protection Light – Indicates BioCote® Present.
Antimicrobial Surface Protection
Firewall Disabled
Page 40 - Revision: EU 17-09-2020
