WARNING! Only trained and qualified technicians should attempt to install, maintain, or service
Waterlogic equipment. Failure to follow all instructions in this manual could result in death, serious
personal injury, or severe property damage.
DANGER! ELECTRICAL SHOCK HAZARD. UNPLUG OR ISOLATE FROM ELECTRICAL SOURCE.
Only qualified personnel who have read and understand this entire manual should attempt to install, or
service this unit, failure to do so could result in death or serious injury. DO NOT plug into an electrical
supply until specifically instructed.
1) Unpack the WL3FW and set on hard level surface as close as possible to electrical and water supply.
Ensure adequate clearance to allow for proper air movement and heat exchange, 100mm (4" min)
minimum required.
2) Remove the filters and flush (follow instructions on filter). Reinstall filters. Always ensure proper
filtration to meet local water conditions and service requirements.
3) Establish 2.7Bar - 4Bar (40–60 psi) 2lpm potable water supply. An accessible shut off and leak
protection is recommended. Always use a pressure regulator.
4) Connect power cord to 220VAC - 50Hz 13 amp outlet or 120VAC – 60Hz 15 amp outlet (Country
dependant).
5) Turn on the RED power switch. GREEN switch MUST remain OFF until the WL3FW tanks are filled or
the hot tank overheat will trip.
CAUTION! NEVER TURN ON HEATER BEFORE FILLING HOT TANK.
Green Compressor/Heater Switch must be in the O=OFF position while the hot tank is empty.
Damage could occur within one minute and the overheat (high limit) will require manual reset if
heater is turned on with an empty hot tank.
6) Fill the hot and cold tanks by dispensing until a steady stream of water flows from each.
7) Turn ON the green power switch to activate the heater and refrigeration systems.
It will take approximately 10 minutes to heat 1.6 Litres of water in the hot tank and 45 minutes to
chill the water to the cold tank to set point temperatures. A warm condenser coil on the back of the
unit indicates the refrigeration system is exchanging heat and operating properly.
WARNING! VERY HOT WATER CAN BURN OR SCALD.
Hot water should be dispensed carefully into insulated container to avoid injury.
8) Function check for flow, temperature, taste, and odour to ensure customer expectations are met.
Inspect and check all connections for leaks/drips and clean unit and area before leaving.
