WaterLogic WL3FW FIREWALL Manual page 30

25 Cold Tank Retaining Nut
26 WL3 upper base panel
JG Equal Elbow Connector 1/4" (PI0308S)
27
28 FW Assembly
Cold Tank Assembly
29
30 JG Equal Straight Connector 1/4"(PI0408S)
JG Equal Elbow Connector 1/4" (PI0308S)
31
32 Solenoid Valve DC24V 1000mm
JG Equal Tee Connector 1/4"
33
JG Equal Elbow Connector 1/4" (PI0308S)
34
35 Solenoid Valve DC24V 1000mm
JG Equal Elbow Connector 1/4" (PI0308S)
36
37 JG Equal Elbow Connector 1/4" (PI0308S)
Double Solenoid valve (Myung) with wire harness assembled
38
39 JG Equal Tee Connector 1/4"
JG Equal Straight Connector 1/4"(PI0408S)
40
JG Equal Elbow Connector 1/4" (PI0308S)
41
42 JG Equal Elbow Connector 1/4" (PI0308S)
JG Equal Straight Connector 1/4"(PI0408S)
43
44 JG Equal Straight Connector 1/4"(PI0408S)
JG Equal Elbow Connector 1/4" (PI0308S)
45
46 Upper Safety Valve 1/4" for Sparkling Unit
47 JG Equal Tee Connector 1/4"
Double Solenoid valve (Myung) with wire harness assembled
48
JG Equal Elbow Connector 1/4" (PI0308S)
49
JG Equal Elbow Connector 1/4" (PI0308S)
50
Unit Control Rubber Feet
51
Mini silver panel Left
52
Side Panel-Left MI-BK-EGI1.2t
Mini Down Base & Chiller white universal as ST-8012
53
Compressor (R600a) 220v/50Hz
54
Compressor (R134a) 120v/60Hz
WL3 Drip Tray Body Black with Firewall Logo
WL3 new drip tray body for WLG Silver-WL with Biocote WL
55
LOGO
WL3 drip tray body Black PHS LOGO -WL with Biocote
WL3 Drip Tray Grill Black
WL3 Drip tray grill -Silver-Biocote added.
56
WL3 Drip tray grill - Black-Biocote added.
WL3 UI (PCB) Label CAS
57
58 WL3 Front Upper Button Cover
WL3 Front Upper Panel Black
WL3 Front upper panel Black
59
WL3 Front upper panel Silver
WL3 LED PCB
60
61 WL3 Display PCB C&A&S, Cold + Sparkling Water 0,5 sec delay
WL3 Display PCB Cover Bracket
62
WL3 Hot Water Faucet
63
Mini silver panel right
64
Side Panel-Right MI-BK-EGI1.2t
