WL3 FW MODEL/PART DESIGNATIONS
BRAND NAME
WL3FW Free Standing
WL3FW Mini
ITEM
Power Supply
Freestanding Dimensions
Width/Depth/Height
Mini Dimensions
Width/Depth/Height
Dispense Opening
Drip Tray Capacity
Cold Water Output
Hot Water Output
Extra Hot Water Output
Output Flow
Input Connections
Recommended Water Feed
Maximum Service Pressure 4 Bar (60 psi) – Always Use Pressure Regulator to Prevent Damage
Feed Water Temperature
Environmental Temperature 2°C - 37°C (35°F - 100°F) - Indoor Use Only
Refrigerant Gas

UV Lamp

Energy Saver Settings
Carbon Block (CBC) Filter
Assembly **
Replacement CBC Cartridge
* See Filter Performance Data Sheet for NSF/ANSI 53 Specifications
** Depending on Technical Agreement, filtration configurations may vary.
WL3 FW Manual
AVAILABLE OPTIONS
F-3FW-FS-CAS - Cold, Ambient, Sparkling
F-3FW-FS-CA – Cold, Ambient
F-3FW-FS-HCA – Hot, Cold, Ambient
F-3FW-FS-HCS – Hot, Cold, Sparkling
F-3FW-M-CAS - Cold, Ambient, Sparkling
F-3FW-M-CA – Cold, Ambient
F-3FW-M-HCA – Hot, Cold, Ambient
WL3 FW GENERAL SPECIFICATIONS
220V/50Hz or 120V/60Hz
395 mm x 365 mm x 1157 mm (15.6" x 14.4" x 45.6")
395 mm x 460 mm x 480 mm (15.6" x 18.1" x 18.9")
220 mm (8.66")
300 ml Removable with optional drain port.
5°C (41°F) Factory Set Point – 4.0 Litre Freestanding/2.0 Litre Mini (on HCA and CA)
87°C (189°F) Factory Set Point – 2 Litre Stainless Tank
Overload (High Limit Safety) 105°C (221°F)
95°C (203°F) Factory Set Point
1.6Lpm - Firewall Purification Rating
¼" Quick Connect Bulkhead for Potable Water
2.7 – 3.5 Bar (40-51 psi) – Always Use Pressure Regulator
2 LPM Maximum Flow – Flow restrictor may be required
32 °C (90°F) Maximum Water Feed Temperature
FS: R600a 26g| R134a: 72g/ Mini: R600a 26g| R134a: 72g
13 Watt – CT-2090
Delivered with Energy Saver Enabled (ON) (heater turns off after 3 hour inactivity)
Disable Energy Sever (Heater is always ON) by moving dip switch on PCB to OFF
FT-0034 Inline Assembly with BioCote Housing – 1 Micron
NSF / ANSI 53 with Lead and Cyst Reduction*
FT-0063 Replacement Cartridge – 1 Micron
NSF / ANSI 53 with Lead and Cyst Reduction*
PART NUMBER
WL3 FW
Page 10 - Revision: EU 17-09-2020
MODEL -
WL-3FW-FS
WL-3FW-M
