Co 2 Installation Procedure - WaterLogic WL3FW FIREWALL Manual

The following instructions are for all models which have a sparkling water option
IMPORTANT INFORMATION
WARNING! Only competently trained people who fully understand the safety precautions
associated with handling gas bottles should attempt to handle, connect or replace CO
Always ensure the CO
CAUTION! The CO
and fitted on a flat surface.
DANGER! Due to calibration reasons, it is advised that the CO
years
Connecting a CO Gas Bottle on installation
2
1. Before starting, ensure the CO
2. Remove the dust cap (where fitted) from the CO
3.
Direct the outlet into a safe location, open the tap on the gas bottle for a second and
close again, this will purge the gas which will clear any dust from the outlet
4. Connect the CO
ring seal is correctly located
5.
Connect the pipework from the regulator to the cooler
6.
Secure the gas bottle in position with a strap or chain so it will not
fall over
7. Open the tap on the gas bottle and set the pressure as required for
that model
8. Check for leaks using Leak Detection Fluid (LDF)
Replacing a CO2 Gas Bottle
1. Close the tap on the CO2 gas bottle currently fitted.
2. Release any pressure in pipework by either dispensing or pulling the pressure relief valve on the
carbonation chamber.
3. Disconnect the CO2 pipework from the cooler
4. Remove CO2 gas bottle from strap or chain.
5. Remove the regulator using a spanner.
6. Give the customer their empty gas bottle to store in a safe location.
WL3 FW Manual
CO INSTALLATION PROCEDURE
2
gas bottle is 'Food Grade'.
2
gas bottle must have a strap or chain to secure the CO
2
gas bottle is food grade
2
pressure regulator and tighten with a spanner, ensuring that the O-
2
gas bottle in position
2
regulator is changed every 5
2
outlet on the bottle
2
Page 15 - Revision: EU 17-09-2020
gas bottles.
2
