FORM 160.54-M1
LEAVING CHILLED
LIQUID TEMPRERATURE
THERMISTOR
REMOTE CURRENT
LIMIT SETPOINT
REMOTE LEAVING
CHILLED LIQUID
TEMP SETPOINT
REMOTE SETPOINT
GND CONNECTIONS
NOTE:
1. Program Jumper JP21 must be positioned on pins 2-3.

FIGURE 23 - CONFIGURABLE ANALOG AND REMOTE SETPOINT INPUTS (HEAT PUMP DUTY)

JOHNSON CONTROLS
J7
71.5 K
2
14
15
+5V
See Note 1
13
7.5 K
4
16
17
+5V
3
J22
1
0-10 VDC /
2-10 VDC
2
0-20 mA /
4-20 mA
3
0-10 VDC /
2-10 VDC
4
0-20 mA /
4-20 mA
5
SECTION 4 - MICROBOARD 031-02430-000 AND 031-02430-001
2
1
47K
JP21
3
200
2
1
JP22
3
2
1
JP23
3
2
1
JP24
3
4
MUX
LD15436
69
