Table 1 - Control Panel Applications - Johnson Controls YORK OPTIVIEW YK Series Service Instructions Manual

YK KC
EVAPORATOR CODE*
MODEL*

TABLE 1 - CONTROL PANEL APPLICATIONS

PART NUMBER
371-02264-101 Electro-Mechanical Starter – NEMA 1
371-02486-101
Electro-Mechanical Starter – CE
371-02448-101 Electro-Mechanical Starter – NEMA 4/12
371-02264-102 Solid State Starter – NEMA 1
371-02486-102 Solid State Starter – CE
371-02448-102 Solid State Starter – NEMA 4/12
371-02264-103 Variable Speed Drive – NEMA 1
371-02486-103 Variable Speed Drive – CE
371-02448-103 Variable Speed Drive – NEMA 4/12
371-02778-101 Electro-Mechanical Starter – NEMA 1 (P Compressors until 8/02)
371-02780-101 Electro-Mechanical Starter – CE (P Compressors until 8/02)
371-02779-101 Electro-Mechanical Starter – NEMA 4/12 (P Compressors until 8/02)
371-02778-102 MOD B Solid State Starter – NEMA 1 (P Compressors until 8/02)
371-02780-102 MOD B Solid State Starter – CE (P Compressors until 8/02)
371-02779-102 MOD B Solid State Starter – NEMA 4/12 (P Compressors until 8/02)
371-02778-103 Variable Speed Drive – NEMA 1-4 (P Compressors until 8/02)
371-02780-103
Variable Speed Drive – CE (P Compressors until 8/02)
371-02779-103 Variable Speed Drive – NEMA 4/12 (P Compressors until 8/02)
371-04118-101 Electro-Mechanical Starter – NEMA 1 (Style F Chillers)
371-04118-102 Style B Solid State Starter – NEMA 1 (Style F Chillers)
371-04118-103 Variable Speed Drive – NEMA 1 (Style F Chillers)
371-04118-110 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications – no VGD – NEMA 1
-111
Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, no J7 compressor – NEMA 1
-112 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, J7 compressor – NEMA 1
371-04119-101 Electro-Mechanical Starter – NEMA 4/12 (Style F Chillers)
371-04119-102 Mod B Solid State Starter – NEMA 4/12 (Style F Chillers)
371-04119-103 Variable Speed Drive – NEMA 4/12 (Style F Chillers)
371-04119-110 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications – no VGD – NEMA 4-12
-111 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, no J7 compressor – NEMA 4-12
-112 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, J7 compressor – NEMA 4-12
371-04120-101 Electro-Mechanical Starter – CE (Style F Chillers)
371-04120-102 Mod B Solid State Starter – CE (Style F Chillers)
371-04120-103 Variable Speed Drive – CE (Style F Chillers)
371-04120-110 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications – no VGD – CE
-111 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, no J7 compressor – CE
-112 Mod B Solid State Starter or Variable Speed Drive w/Modbus Communications and VGD, J7 compressor – NEMA 1
4
NOMENCLATURE
K4 H9
COMPRESSOR CODE*
CONDENSER CODE*
– CY
MOTOR CODE
POWER SUPPLY
– for 60Hz
5 for 50Hz
* Refer to YK Engineering Guide (Form 160.75-EG1) for
Shell/Motor/Compressor combinations.
DESCRIPTION
FORM 160.54-M1
G
STYLE (Design Level)
