SECTION 20 - TEMPERATURE THERMISTORS

TABLE 18 - DROP LEG REFRIGERANT SENSOR

TEMP (°F) TEMP (°C)
0.01 -17.77
3.72 -15.71
7.21 -13.77
10.51 -11.94
13.65 -10.20
16.65 -8.53
19.56 -6.91
22.36 -5.36
25.09 -3.84
27.74 -2.37
30.34 -0.92
32.89 0.49
35.40 1.89
37.87 3.26
40.31 4.62
42.73 5.96
45.14 7.30
47.53 8.63
49.92 9.96
52.31 11.28
54.70 12.61
57.10 13.95
59.52 15.29
61.95 16.64
64.40 18.00
66.89 19.38
69.40 20.78
71.97 22.21
74.57 23.65
77.23 25.13
79.96 26.65
82.73 28.19
85.60 29.78
88.56 31.42
91.59 33.11
94.75 34.86
98.06 36.70
101.50 38.61
105.10 40.61
108.90 42.73
112.92 44.96
117.17 47.32
121.76 49.87
174
VIN
0.753
0.831
0.909
0.987
1.066
1.144
1.222
1.300
1.378
1.456
1.534
1.613
1.691
1.769
1.847
1.925
2.003
2.081
2.160
2.238
2.316
2.394
2.472
2.550
2.628
2.707
2.785
2.863
2.941
3.019
3.097
3.175
3.254
3.332
3.410
3.488
3.566
3.644
3.722
3.801
3.879
3.957
4.035

TABLE 19 - EVAPORATOR REFRIGERANT SENSOR

TEMP (°F) TEMP (°C)
0.04 -17.76
2.79 -16.23
5.44 -14.76
8.02 -13.32
10.53 -11.93
12.98 -10.57
15.39 -9.23
17.75 -7.92
20.08 -6.62
22.38 -5.34
24.66 -4.08
26.92 -2.82
29.17 -1.57
31.41 -0.33
33.66 0.92
35.90 2.17
38.15 3.42
40.41 4.67
42.69 5.94
44.99 7.72
47.31 8.51
49.67 9.82
52.06 11.15
54.49 12.50
56.96 13.87
59.50 15.28
62.10 16.72
64.77 18.21
67.51 19.73
70.35 21.31
73.29 22.94
76.36 24.65
79.55 26.42
82.89 28.27
86.41 30.23
90.12 32.29
94.07 34.49
98.31 36.84
102.87 39.38
107.81 42.12
113.26 45.15
119.30 48.50
126.10 52.28
FORM 160.54-M1
VIN
1.135
1.214
1.292
1.370
1.448
1.526
1.604
1.683
1.761
1.839
1.917
1.995
2.073
2.151
2.230
2.308
2.386
2.464
2.542
2.620
2.698
2.777
2.855
2.933
3.011
3.089
3.167
3.245
3.324
3.402
3.480
3.558
3.636
3.714
3.792
3.871
3.949
4.027
4.105
4.183
4.261
4.339
4.418
