This chapter contains general information and detailed specifications of the ICO330. The
Chapter 1 includes the following sections:
◼

General Description

◼ System Specification
◼ Dimensions
◼ I/O Outlets
1.1 General Description
ICO330 Din-rail fanless embedded system is suitable for communications control and for
protocol converter applications in critical environments. Built for rugged work environments,
ICO330 features an extra low power consumption Intel
(1.5GHz) processors supporting industrial temperature range of -40℃ to +70℃. Its front
accessible I/O cabling is very convenient for wiring and maintenance. ICO330 offers a HDMI
output, making it particularly well-suited for data acquisition, communication control, SCADA
and industrial automation. Its compact size with Din-rail mounting allows for easy installation
into control cabinet. Pre-installed (optional) with Linux, Windows
programmers with a friendly environment for developing application software at a lower cost.
ICO330 is robust industrial-grade hardware design, besides, supporting the mSATA, SATA
SSD, which makes it especially suitable for field control & monitoring system solution for
following markets:
Utility Industries (Water; Energy; Chemical Plant; Mining...)
Public Transportation Industries (Traffic/ Highway Control; Train/Bus Control...)
Homeland Security (Weather Monitoring/Alarm System...)
⚫ Checklist (Slim Mode)
✓
ICO330 System Unit x 1
✓
DDR thermal pad x1
✓
M.2 Key B thermal pad x1
✓
Screws for Mini Card M2*5L x2
✓
Screws for SSD/HDD M3*4L x4
✓
Screws for M.2 KeyB M3*3L x1
✓
Screws for HDMI BKT M3*5L x1
✓
Power 3 pin terminal block x 1
Introduction
® ®
Atom x6212RE(1.2GHz) or x6414RE
✓
Din-rail Kit x1Set
✓
COM 2x5pin termninal block x2
✓
SATA+Power SSD cable x1
✓
HDMI BKT x1
✓
Cable Tie and Holding Kit for HDMI x1
✓
Thermal sheet block for DDR x1
✓
Thermal sheet block for M.2 KeyB x1
ICO330 Series User's Manual
SECTION 1
INTRODUCTION
®
10/11 IoT, ICO330 provides
