Introduction

The Phantom 2 ITX Case turns the Singularity Computers PowerBoard into the case itself.
Phantom 2 does not aim to be the smallest Mini-ITX case, but to achieve maximum component
density with unrestricted airflow and support for high-end watercooling. Phantom 2 disappears
amongst the components mounted to it, it is completely about component selection and will
show off the skill of the builder. It fits ITX motherboards, 4 slot graphics cards, ATX power
supplies and 2x 2.5" drives. Water-cooling is possible with the included Phantom 2 Universal
Radiator Mount which fits 120mm, 140mm, 240mm, 280mm, 360mm, 420mm, 480mm and
560mm radiators. There is no limitation on radiator thickness and push/pull fans also fit. All
components are mounted directly onto the PowerBoard which acts as a rack as well as a power
distribution plate. It has the MB 24pin, EPS 8pin, pump power, a temperature controlled PWM hub
for the fans and the D5 pump integrated along with Power and Reset buttons and a JUMPSTART
PSU switch. There are integrated direct connect SATA power connections to avoid the use of SATA
power cables. It has built-in ARGB and UV lighting. There is no rear access needed to the case for
cable management, all cables can be connected from the front. Black sleeved cables are included
with the case and custom colored sleeved linking cables can be purchased separately.

Features

PowerBoard Integration
•
The Phantom 2 PowerBoard is a PCB integrating 24pin, EPS, SATA, Power, and Reset Buttons
with PWM control, ARGB and UV lighting. Essentially, the PowerBoard is a distribution plate for
cables while integrating other features and functions as well. It is a new method for cables
allowing standardisation of cable lengths and making traditional cable management no longer
necessary. Phantom 2 comes included with a standard set of black sleeved linking cables
including 24pin x1 and 8pin EPS x1 meaning that these cables don't have to be purchased
separately.
Reduced build time due to integration
•
Cables do not need to be purchased separately and no cable management is needed for the
core component cables.
High End Components
•
It is designed to fit the largest high-end GPUs. It can fit the largest PSUs although it is
recommended to pick a short and light PSU to make transporting the system easier, same
applies to the GPU. For the water-cooling system it can fit any 120mm or 140mm class radiator
size with unlimited thickness and push/pull fans.
Radiator Adjustment
•
The additional Phantom 2 Universal Radiator Mount is adjustable to help with port alignment
and to turn the radiator into a support leg.
Storage
•
The Phantom 2 PowerBoard has 2x 2.5" SATA Drive positions.
