  • Page 1 Revision 1.0...

  • Page 2: Table Of Contents

    SC Test Bench Manual Table of Contents Introduction ................................2 Features Overview .............................. 2 Specifications ............................... 3 Parts List ................................4 Installation ................................4 PowerBoard ................................7 Test Bench D5 Reservoir Distribution Plate Port Layout ..............8 Revision 1.0 Page | 1...

  • Page 3: Introduction

    The SC Test Bench fits radiators on both sides up to 480mm or 560mm and x3 more 140mm fans on the front. There will also be a pump/reservoir distribution plate add-on which will mount onto the front.

  • Page 4: Specifications

    PWM Female to Female 50cm Black Sleeved x2. ARGB Female to Female 50cm Black x1. Power, Reset, Black 20cm. Pump Power Cable 4pin ATX to SATA & Molex x2. SC Test Bench D5 Reservoir Distribution Plate Distribution Plate Cast Acrylic, Clear, CNC Machined. Integrated.

  • Page 5: Parts List

    SC Test Bench Manual Parts List SC Test Bench Cables Hardware  8pin PCIe 30cm Linking cable x3 / 12VHPWR 30cm x1  M3 6mm Button Head x26  PWM Linking Cable 50cm x2  M4 6mm Button Head x13...
  • Page 6 SC Test Bench Manual A 2.5” drive can be installed to the back panel using 2x M3 6mm BH fasteners and the SATA data and power cables can be routed under the PowerBoard or the motherboard. If radiators are going to be used in the system, install them now to the sides using the radiators’...
  • Page 7 SC Test Bench Manual To the front of the case, we can attach up to 3x 140mm fans using M4 30mm BH for 25mm thick fans or M4 35mm BH fasteners for 30mm thick fans, or a D5 distribution plate using 6x M4 14mm BH fasteners.

  • Page 8: Powerboard

    SC Test Bench Manual PowerBoard  All PowerBoards need PowerBoard Linking Cables. Revision 1.0 Page | 7...

  • Page 9: Test Bench D5 Reservoir Distribution Plate Port Layout

    SC Test Bench Manual Test Bench D5 Reservoir Distribution Plate Port Layout Revision 1.0 Page | 8...
