- Page 1 Revision 1.0...
-
Page 2: Table Of Contents
| Arterial 2 Manual Table of Contents Arterial 2 Mini Dual 240mm Water-box ....................2 Specifications & Included Items ........................2 Dimensions & Port Layout ..........................2 Pump Installation ..............................3 Filling & Draining ..............................3 Arterial 2 Dual 560mm Water-box ......................4 Specifications &... -
Page 3: Arterial 2 Mini Dual 240Mm Water-Box
| Arterial 2 Manual Arterial 2 Mini Dual 240mm Water-box Arterial 2 Mini Dual 240mm Water-box is a dedicated high-end water-cooling enclosure with a distribution plate which integrates a reservoir and pump top. It fits dual 45mm thick 240mm radiators with a single set of fans and a DDC. All components are CNC machined, the enclosure is built from 3mm 6061 aluminum, the distribution plate from cast acrylic and the fasteners are stainless steel. -
Page 4: Pump Installation
Do not over tighten fasteners on acrylic. Filling & Draining Arterial 2.0 Water-boxes have a dedicated fill and drain port. When filling it is best to connect a fill tube at least 20cm long. This is to prevent any overflow from back flow when the pump/s are turned off and helps to get the last of the air out. -
Page 5: Arterial 2 Dual 560Mm Water-Box
CNC machined, the enclosure is built from 3mm 6061 aluminum, the distribution plate from cast acrylic and the fasteners are stainless steel. Arterial 2 has been completely redesigned. The enclosure is now built from folded aluminum which greatly improves strength and gives a more streamlined aesthetic. All ventilation is now dust filtered. - Page 6 | Arterial 2 Manual Step 2 Attach the Distribution Plate Panel to the chassis using the included M4 6mm Fasteners x10 which are marked in the diagram. Step 3 Attach the side panel window using the included M4 12mm Fasteners x6 which are marked in the diagram.
-
Page 7: Dimensions & Port Layout
D5 Pump Cover. Filling & Draining Arterial 2.0 Water-boxes have a dedicated fill and drain port. When filling it is best to connect a fill tube at least 20cm long. This is to prevent any overflow from back flow when the pump/s are turned off and helps to get the last of the air out.
