Step 8: Cable Installation

•
Required 8pin EPS 10cm Linking Cable
•
Parts 24pin MB 10cm Linking Cable
•
"POWER SW" Wire
•
"RESET SW" Wire
Install the included 8pin EPS and 24pin MB Linking Cables to the motherboard's appropriate
connectors. Orientation does not matter. If 2.5" drives are installed, connect the motherboard to
the PowerBoard with SATA 10cm DATA Cables. SATA-1 is connected to DRIVE-1, SATA-2 is to
DRIVE-2. Plug in the included "POWER SW" and "RESET SW" wires to the motherboard front panel
header and to the PowerBoard's "RST-PWR" header to enable the POWER and RESET button
functionality. Connect the FAN-IN header to one of the motherboard's PWM headers with the
PWM Linking Cable to allow for PWM control and RPM reading of the fans plugged into the
PowerBoard. Connect the ARGB-IN header to an ARGB output header on the motherboard to
enable and control the PowerBoard's built-in ARGB lighting and ARGB hub.
Plug in an optional temperature sensor to the 2pin header labeled "T". This header accepts 10K
NTC-type thermistors which are available as a stop fitting from major brands.
Revision 1.0
Phantom 2 ITX Case Assembly Manual
•
x2 SATA 10cm Data Cable x2
•
PWM Linking Cable
•
ARGB Linking Cable
•
Temperature sensor (purchased separately)
