Page 2: Table Of Contents
Phantom ITX/DTX Case Assembly Manual Table of Contents Introduction ..............................2 Features ................................2 Phantom ITX/DTX Case Specifications ....................3 Parts List................................. 4 Assembly Manual ............................5 Step 1: Mounting the Drives ..........................5 Step 2: Preparing the Main PowerBoard ...................... 5 Step 3: Installing the Power Supply ...................... -
Page 3: Introduction
Phantom turns the Singularity Computers PowerBoard into the case itself. The goal was to create the most minimalistic case using PCB only. Phantom does not aim to be the smallest Mini-ITX case, but to achieve maximum component density with unrestricted airflow. Phantom disappears amongst the components mounted to it, it is completely about component selection and will show off the skill of the builder. -
Page 4: Phantom Itx/Dtx Case Specifications
Phantom ITX/DTX Case Assembly Manual Phantom ITX/DTX Case Specifications Case Components PowerBoard parts: x10 total. Stainless steel fasteners and stand offs. Electronics Integration Core Component Cables: 24pin x1, 8pin EPS x1, Power and Reset Buttons. 2.5”/ 3.5” SATA 3.0 6Gb/s Direct Mount x1 2.5”... -
Page 5: Parts List
Building a Phantom system is an orderly process and missing steps or hardware could result in having to undo multiple steps. All mounting holes are marked on the Phantom PowerBoard pieces and there are legends on the main board that show which mark calls for which assembly hardware. -
Page 6: Assembly Manual
Phantom ITX/DTX Case Assembly Manual Assembly Manual Step 1: Mounting the Drives • Required #6-32 0.25” SCR • Parts M3 4mm SCR Mount the storage devices to the main PowerBoard before doing any other assembly as access to these drives will be restricted by other parts. -
Page 7: Step 3: Installing The Power Supply
PowerBoard at the mounting holes marked with “M” on the lower back side. These will need to be tightened reasonably well as the Phantom PowerBoard gains its structural integrity mostly from these mounts. -
Page 8: Step 5: Pcb Reinforcements And Covers
Phantom ITX/DTX Case Assembly Manual Step 5: PCB Reinforcements and Covers • Required #6-32 0.25” SCR Parts Grab the PCB cover pieces and mount them to their designated locations. The areas are marked with a white outline on the back side of the main PowerBoard that match the shape of the cover pieces and secure them with a total of x19 #6-32 0.25”... -
Page 9: Step 7: Installing The Motherboard
PowerBoard. If using a dedicated graphics card then plug in the PCIe power cables to the power supply and the graphics card. Singularity Computers can provide custom length sleeved cables for most power supplies. Revision 1.0... -
Page 10: Phantom Powerboard
Phantom ITX/DTX Case Assembly Manual Phantom PowerBoard All PowerBoards need PowerBoard Linking Cables. Revision 1.0 Page | 9...
