Chapter 2: Jumpers and Connectors
Connector Pin Definitions
24-pin ATX Power Connector
Connector type: 2x12 24-pin boxed header
Connector location: EATX_PWR1
1
1
13
2
Pin
Definition
1
+3 Volts
3
+3 Volts
5
GND
7
+5 Volts
9
GND
11
+5 Volts
13
GND
15
Power OK
17
+5V Standby
19
+12 Volts
21
+12 Volts
23
+3 Volts
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
23
12
24
24
Pin
Definition
2
+3 Volts
4
-12 Volts
6
GND
8
PSON#
10
GND
12
GND
14
GND
16
-5 Volts
18
+5 Volts
20
+5 Volts
22
+5 Volts
24
GND
8-pin ATX Power Connector
Connector type: 2x4 8-pin boxed header
Connector location: EATX_PWR2
8
5
4
1
Pin
Definition
1
GND
3
GND
5
GND
7
GND
12
Pin
Definition
2
+12V
4
+12V
6
+12V
8
+12V
NEX 913 User Manual
