Chapter 2: Jumpers and Connectors

Jumpers

CMOS Clear Selection

Connector type: 1x3 3-pin header
Connector location: CLRTC1
1 3
Pin Settings
1-2 On Normal
2-3 On Clear CMOS
1-2 On: default
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.

COM1 RS422/485 Terminator

Connector type: 1x2 2-pin header
Connector location: J1, J2, J3 and J4
J3 J4
1 2 1 2
1 2 1 2
J2 J1
Pin
J1, J2, J3, J4 All Off
J1, J2, J3, J4 All On
J1, J2, J3, J4 On: default
9
Settings
RS232
RS485/RS422 with terminator
