Chapter 3: BIOS Setup
System Agent (SA) Configuration
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Chipset
Memory Configuration
Memory Frequency 2400 MHz
Total Memory 4096 MB
Channel 0 Slot 0 Not Populated / Disabled
Channel 0 Slot 1 Not Populated / Disabled
Channel 1 Slot 0 Not Populated / Disabled
Channel 1 Slot 1 Populated & Enabled
Size 4096 MB (DDR4)
Number of Ranks 1
Manufacturer UnKnown
Max TOLUD [Dynamic]
Primary Display [Auto]
Primary IGFX Boot Display [VBIOS Default]
PCIEX16 Gen Speed [Auto]
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Max TOLUD
Configures the maximum value of TOLUD.
Primary Display
Select which IGFX/PEG/PCI graphics device should be the primary display or
select SG for Switchable Gfx.
Primary IGFX Boot Display
Select the video device which will be activated during POST. Has no effect
if external graphics is present. Secondary boot display selection will appear
based on your selection. VGA modes will be supported only on primary display.
PCIEX16 Gen Speed
Configures the maximum link speed of the PEG device.
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
PCH-IO Configuration
Maximum Value of TOLUD.
Dynamic assignment would
adjust TOLUD automatically
based on largest MMIO length
of installed graphic controller
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
HD Audio
Control detection of the HD Audio device.
Disabled
Enabled
PCIEX1_1, PCIEX1_2, PCIEX4_1 and PCIEX4_2 Gen Speed
Configures the maximum PCIe speed of PCIEX1_1, PCIEX1_2, PCIEX4_1 and
PCIEX4_2.
37
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Chipset
PCH-IO Configuration
HD Audio [Enabled]
PCIEX1_1 Gen Speed [Auto]
PCIEX1_2 Gen Speed [Auto]
PCIEX4_1 Gen Speed [Auto]
PCIEX4_2 Gen Speed [Auto]
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
HD Audio will be unconditionally disabled.
HD Audio will be unconditionally enabled.
Control Detection of the
HD-Audio device.
Disabled = HDA will be
unconditionally disabled
Enabled = HDA will be
unconditionally enabled
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
