Chipset - Nexcom NEX 913 User Manual

Chapter 3: BIOS Setup
Digital IO Port Configuration
This section is used to configure digital I/O port settings.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
Digital IO Port Configuration
DIO Port1 [Output]
Output Level [High
DIO Port2 [Output]
Output Level [High
DIO Port3 [Output]
Output Level [High
DIO Port4 [Output]
Output Level [High
DIO Port5 [Input ]
DIO Port6 [Input ]
DIO Port7 [Input ]
DIO Port8 [Input ]
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
DIO Port1 to DIO Port8
Configures DIO port1 to port8 as input or output.
Output Level
Configures the output level as high or low.
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Set DIO as Input or Output
]
]
]
]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Chipset

This section gives you functions to configure the system based on the
specific features of the chipset. The chipset manages bus speeds and access
to system memory resources.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Main Advanced Chipset
► System Agent (SA) Configuration
► PCH-IO Configuration
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
System Agent (SA) Configuration
Enters the System Agent (SA) Configuration submenu.
PCH-IO Configuration
Enters the PCH-IO Configuration submenu.
36
Security Boot Save & Exit
System Agent (SA) Parameters
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NEX 913 User Manual
