Chapter 2: Jumpers and Connectors

2xFM MCU Programm Header

Connector location: JP2
5 1
Pin Definition
1 +P3V3_AUX
3 GND
5 2xFM_MCU_RST_B
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 SWCLK
4 SWDIO_2xFM

MCU Programm Header

Connector location: JP3
5 1
Pin Definition
1 +P3V3_AUX
3 GND
5 MCU_RST_B
17
Pin Definition
2 SWCLK
4 SWDIO
