Guardian Fall Protection CB-1-B Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Product Name: CB-1-B
Part #: 00600; 00600-SS; 00601; 10685
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
Introduction
Applicable Safety Standards
Worker Classifications
Product Specific Applications
Limitations
Components and Specifications
Installation and Use
Maintenance, Cleaning, and Storage
Inspection
Inspection Log
Safety Information
Labels
1
1
2
2
3 - 4
4
5 - 6
7
7
7
8
9 - 10

Advertisement

loading
Need help?

Need help?

Do you have a question about the CB-1-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Guardian Fall Protection CB-1-B

Summary of Contents for Guardian Fall Protection CB-1-B

  • Page 1 Product Name: CB-1-B Part #: 00600; 00600-SS; 00601; 10685 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications Limitations 3 - 4 Components and Specifications...
  • Page 3 CB-1-B Anchors do not comply with ANSI/IWCA I-14.1-2001 Section 9 requirements for tie-back/suspension anchorages for window washing or facade maintenance equipment. CB-1-B Anchors do not comply with CalOSHA section 3291 (f) for roof tie-back/suspension anchorages, which are required on all buildings in California above 36’ (or three stories), with certain rare exceptions.
  • Page 4 Maximum 1 attachment per connection point. Personal Fall Arrest: CB-1-B Anchors may be used to support a MAXIMUM 1 personal fall arrest system (PFAS) for use in Fall Arrest applications. Structure must withstand loads applied in the directions permitted by the system of at least 5,000 lbs., or achieve a minimum 2:1 safety factor, as...
  • Page 5 5’ Compatibility: When making connections with 2’ *Eliminate Swing Fall whenever CB-1-B, eliminate all possibility of roll-out. Roll-out possible! If Swing Fall exists, occurs when interference between a hook and always account for additional 1.5’...
  • Page 6 -30° F. installation holes (x4) 5,000 lb. MBS (minimum breaking strength). Materials: powder-coated steel, stainless steel, or galvanized steel (see table). Part # Description 00600 CB-1-B (Powder-Coated Steel) 00600-SS CB-1-B (Stainless Steel) 00601 CB-1-B (Galvanized Finish) 10685 CB-1-B Backer Plate...
  • Page 7 2. Eliminate or minimize all risk of swing fall. 3. Ensure structure to which CB-1-B is to be installed, and on which work is to be performed, is free of all hazards, including, but not limited to, debris, rot, rust, sharp or abrasive edges and surfaces, and hazardous materials.
  • Page 8 Installation, CB-1-B (part # 00600, 00600-SS, and 00601) Wood/Steel/Concrete Installations: 1) Ensure substrate and fasteners comply with all minimum requirements. 2) Place CB Anchor at selected installation location. For wood installations, drill (4) 5/16” pilot holes. 3) Install all fasteners until snug, and ensure CB Anchor is fully secured to substrate.
  • Page 9 Cleaning after use is important for maintaining the safety and longevity of CB-1-B. Remove all dirt, corrosives, and contaminants from CB-1-B before and after each use. If CB-1-B cannot be cleaned with plain water, use mild soap and water, then rinse and wipe dry. NEVER clean CB-1-B with corrosive substances.
  • Page 10 Safety Information Failure to understand and comply with safety regulations may result in serious injury or death. Regulations included herein are not all-inclusive, WARNING are for reference only, and are not intended to replace a Competent Person’s judgment or knowledge of federal or state standards. Do not alter equipment.
  • Page 11 Labels CB-1-B Compliant with OSHA 1910.140, OSHA 1926.502, ANSI Z359.18-2017, and ANSI Part #: 00600 A10.32-2023 regulations. guardianfall.com DOM: Type A anchorage connector. Prior to use, read and understand all instructions 5,000 lb. MBS (min. breaking strength). provided with equipment.
  • Page 12 Labels CB-1-B Compliant with OSHA 1910.140, OSHA 1926.502, ANSI Z359.18-2017, and ANSI Part #: 00601-SS A10.32-2023 regulations. guardianfall.com DOM: Type A anchorage connector. Prior to use, read and understand all instructions 5,000 lb. MBS (min. breaking strength). provided with equipment.

This manual is also suitable for:

0060000600-ss0060110685
