Use of Cable Bushings
The cable bushings included in the
the following cables:
Big bushing: for two cables of the diameter of 5–6 mm (two-wire cable), or,
upon insert replacement, for one thick cable/tube of the diameter of up to 14
mm.
Small bushing: for one cable of the diameter of 5–8 mm.
Tip
Even a LAN cable including the RJ-12 connector can go through the big
bushing. See below for instructions.
How to Pull a RJ-12 Terminated Cable through a Bushing
1. Unscrew the big bushing nut completely.
2. Remove the sealing including the cover from the bushing. Cut either of the
components as shown in the figures.
3. Put the bushing nut on the cable and insert the sealing.
