Flush Mounting – Hollow Bricks
Suppose you intend to install your
hollow bricks. Note that the external side of the bricks gets damaged by cutting and
the dowels cannot practically be fixed into the thin internal part of the bricks.
Therefore, use the brick flush mounting box and follow the instructions included
therein.
What You Need:
Brick flush mounting box, Part No. 9151001
Hole: (132 × 223 × 83) mm
Wall Mounting
Wall (surface) mounting is used where flush mounting is inapplicable (in concrete and
steel structures, entry barrier columns, etc.). The frame is not used.
What You Need:
Just your 2N unit
2N TELEKOMUNIKACE a.s., www.2n.cz
®
2N Analog Force/Safety unit into a wall made of
