button backlight and electric lock, if connected. Nevertheless, 2N
/Safety can work without these circuits too (amplifier is bypassed in this case).
Analog Force/Safety
after having been disconnected from the line for a defined period of time).
External Power Supply and Electric Lock Connection
®
2N Analog Force/Safety
Built-in audio amplifier – current draw of up to 100 mA,
1.
Name tag and keypad backlight – current draw of up to 150 mA
2.
Electric lock – current draw according to the lock type
3.
The electric lock can be fed from the same source as the intercom or another supply.
®
2N Analog Force/Safety
AC and DC regardless of polarity. Make sure that the current and voltage values do
not exceed limits (refer to the Technical Data) and that the technical parameters of
the lock and power supply are compatible.
Warning
Never switch 230 or 120 V mains voltage directly!!!
Caution
If the lock power supply fails and the telephone system carries on
working, the intercom is unaware of the failure the switch will be
password-activated and the activation is acoustically signalled, but the
electric lock will not work because of the lack of power.
Ground connection is mandatory. If used power supply output is
grounded, you can connect GND terminal to it.
2N TELEKOMUNIKACE a.s., www.2n.cz
sends an acoustic signal on having been connected to a line (or
require 12 V ( DC only!
contains a solid-state switch, which is able to switch both
) supply for:
®
Analog Force
®
