General Information
Figure 2-31.
General Info
Battery Condition:
Figure 2-31. General Info (Page 2)
See Figure 2-32. Use page 3 to view the currently in-
stalled versions of hardware, bootloader, firmware, and
firmware build.
Figure 2-32.
General Info
Hardware
Bootloader
Firmware
Firmware Build
Figure 2-32. General Info (Page 3)
See Figure 2-33. Use page 4 to view the currently in-
stalled versions of the Engine Control Unit (ECU) and
Electronically Erasable Programmable Read-only Memo-
ry (EEPROM).
Figure 2-33.
General Info:
ECU
EEPROM
Figure 2-33. General Info (Page 4)
See Figure 2-34. Use page 5 to view the currently in-
stalled versions of I/O Extender hardware and firm-ware.
18
CHECK BATTERY
013021
V x.xx
V x.xx
V x.xx
xxxx
013022
V x.xx
V x
013023
Figure 2-34.
General Info:
I/O Ext. 1
I/O Ext. 2
I/O Ext. 3
I/O Ext. 4
Figure 2-34. General Info (Page 5)

Alarm Screen

See Figure 2-35. The Alarm Screen contains information
for viewing only. Use the navigation arrows (
scroll through alarms. Press STOP (
( ) while on the Alarm Screen to clear all alarms
present.
Figure 2-35.
FT ECODE Active Fault
A 2801 Aux Shutdown
W 2710 Ruptured Tank
M Battery Maint Due
Figure 2-35. Alarm Screen (Page 1)

Modify a Page Setting

1. See Figure 2-36. Verify the desired setting is high-
lighted on the page and press the ENTER button (
).
Figure 2-36.
User Edit
Adjust Voltage
Set Language
Set Date/Time
Set Exercise
Figure 2-36. Highlight Page Setting
2. See Figure 2-37. Press the ENTER button again to
highlight the value if needed. If multiple settings are
Power Zone 410
HW FW
V xxxx xxxx
V xxxx xxxx
V xxxx xxxx
V xxxx xxxx
013024
) and then ENTER
013025
013026
® Controller Owner's Manual
) to
