General Information
See Figure 2-8. This screen will display only if the unit is
not activated. Use page 4 to enter the unit serial number
and activation code. See the unit owner's manual to lo-
cate the unit serial number. The activation code can be
obtained at www.activategen.com
Figure 2-8.
Activate
To activate go to
www.activategen.com
SN xxxxxxxxxx
Code
Figure 2-8. Wizard Screen (Page 4)
See Figure 2-9. Page 5 will display only if an incorrect ac-
tivation code was entered. Three attempts are given to
enter the correct code.
Figure 2-9.
Activate
Wrong Activation Code
Figure 2-9. Wizard Screen (Page 5)
See Figure 2-10. Use page 6 to set the date and time to
appear on the Home Screen.
Figure 2-10.
Set Date/Time
Set Date:/Set Time:
04/20/21
Figure 2-10. Wizard Screen (Page 6)
See Figure 2-11. This screen will display only if Vcode
settings have never been set. Use page 7 to set the fuel
type to liquid propane or natural gas.
14
xxxxx
012981
3
012982
07:53am
012983
Figure 2-11.
Edit:
Select Fuel Type =
Figure 2-11. Wizard Screen (Page 7)
See Figure 2-12. This screen will display only if Vcode
settings have never been set. Use page 8 to configure
quiet test, set exercise time and duration, and transfer
frequency.
Figure 2-12.
Set Exercise
Con g Quiet Test
hh:mmxx
Duration:
Xfer:
Figure 2-12. Wizard Screen (Page 8)

Engine Screen

The pages within the Engine Screen contain information
for viewing only. Use the navigation arrows (
igate between the screens.
See Figure 2-13. Page 1 displays the generator RPM,
coolant level, coolant temperature, and unit run time.
Figure 2-13.
Engine
Generator RPM
Coolant Level
Coolant Temp.
Run Hours
Figure 2-13. Engine Screen (Page 1)
Power Zone 410
NG
012986
xx
Monthly
xxxxxxxxx
xx Min
xxxxx
012987
) to nav-
xxx
xxx
xxxF
xxx:xxh:m
012988
