Input/Output and Connector Info

CAN/CURRENT/ANALOGS

J3 18 Pin Signal
1 Can-HI
2 Can-LO
3 Can-Shield
4 CurrentA(+)
5 CurrentA(-)
6 CurrentB(+)
7 CurrentB(-)
8 CurrentC(+)
9 CurrentC(-)
10 CoolantTemp(analog)
11 CoolantTemp(ret)
12 Oil Pressure(+5V)
13 Oil Pressure(analog)
14 Oil Pressure(ret)
15 FuelPressure/Level(+5)
16 FuelPressure/Level(signal)
17 FuelPressure/Level(ret)
18 Spare DigIn/Chicago Code

USER

J9 8 Pin Signal
1 E-Stop 12V
2 E-Stop In
3 KeyswitchPresent(in)
4 KeyswitchPresent(gnd)
5 +12V Alarm
6 Audible Alarm
7 Keyswitch(1)
8 Keyswitch(2)

POWER/RELAYS

J10 16 Pin Signal
1 +12VBatt
2 +12VBatt
3 +VBatt
24
Board Connection Description
120 Ω between CAN HI & CAN LO
120 Ω between CAN HI & CAN LO
–
–
–
–
–
–
–
max input 3.3 V
–
Fused for 50 mA
max input 5.0 V
–
+5 V through 499 Ω resistor
Feedback from pot or switch
–
5 V pullup
Board Connection Description
Dry contact
Dry contact
5 V pullup
–
–
Open drain
5 V pullup
5 V pullup
Board Connection Description
On board 7.5 Amp fuse
On board 7.5 Amp fuse
Externally fuse for 10 A
Wire #
743
744
SHLD
398A
399A
399B
399B
398C
399C
68V
68R
69V
69S
69R
590
575
591
735
Wire #
–
–
–
–
–
–
–
–
Wire #
SPLICE 4
SPLICE 4
SPLICE 11
Power Zone 410 ® Controller Owner's Manual
