General Information
• Engine Oil Pressure
• Engine Oil Temperature
• Battery Voltage
• Warning and Alarm Indication
• Diagnostics
• Maintenance Events/Information
• Hourmeter

Control Panel

• AUTO/OFF/MANUAL
• Operation Through Onboard Buttons or Optional
Key Switch
• Indication Through Display Screen and LEDs
• Audible Alarm and SILENCE†
• Auxiliary Shutdown Rocker Switch
• Not in AUTO Indication
† If equipped; see modular NFPA 110 components
section.
Voltage Regulation (Single or Three-Phase
Module Options)
• Digital Control
• Three-Phase Sensing
• Variable V/F Slope Settings
• Negative Power Limit
• Loss of Sensing Protection
• Fault Protection (I2T Function)
• High Voltage Limit
• Low Voltage Limit
• Maximum Power Limit
• ±0.5% Voltage Regulation
• ±0.5% Stability
• Governor Functionality
• Speed Control through ECM Integration
• Soft Start Ramping (Multiple Steps)

Communication Ports

• 2 RS-232
• 2 RS-485
• 1 CANBus

Qualification Testing

• Life Test in Environmental Chamber
• Temperature Rating -40 °C to +70 °C
• Vibration Tested and Protected
10
Connections ‡
• 16 Analog Inputs
• 6 AC Voltage Sensing Inputs
• 3 CT Inputs
• 30 Digital Inputs
• 17 Digital Outputs
• Comms Ports
• 1 CANbus Port
• 1 USB Port (for Configuration Transfer and Firm-
ware Upgrades)
• 1 RS-485 Modbus Master Port (for External RAP/
RRP/External I/O Modules)
• 1 RS-485 Modbus Slave Port (for other uses, e.
g. Building Management)
• 2 RS-232 Communication Ports
‡ Actual I/O may vary due to configuration.

Codes And Standards

• UL 6200
• CE
• NFPA 110 Capable
Modular NFPA 110 Components§
• Remote Annunciator
• NFPA Accessory Module
• Key Switch
• Alarm Horn
• Emergency Stop
• 10A External Battery Charger
§ If equipped; not standard on all models

Panel Setup

The Power Zone 410 Control Panel controller is setup in
the factory to match the product it is shipped with and
generally no changes are required. For spares purposes
the controller can be re-configured in the field using Dis-
play functions.
To change the function of the panel, the only way to get a
basic setup for a product is to use the controller's display.
This will setup all the basic parameters and just leave
customization and calibration to be done. Contact cus-
tomer support for other customizations not available
through the display.
Below are examples of some of the configurations adjust-
able using the display:
• Setting Display Contrast
• Setting System Time and Date
• Setting Up/Enabling Internal Exercise
