Power Zone 410 Service Tool - Generac Power Systems Power Zone 410 Owner's Manual

Displayed Alarm
E-Code
Engine Fuel Valve
4917
1 Position
Engine Charge Air
5003
Cooler 1 Bypass
Engine Charge Air
5004
Cooler 1 Bypass
Engine Speed
5100
Engine Speed
5101
Engine Speed
5102
Engine Speed
5107
Engine Speed
5115
Engine Speed
5117
High Manifold In-
7620
take Temp

Power Zone 410 Service Tool

Additional interfacing for configuration and setup is avail-
able to an IASD using the Power Zone 410 Service Tool.
Power Zone 410 ® Controller Owner's Manual
Alarm/
Warning
Fuel Mixer — Data valid but below normal operating range; least severe
W
level.
CAC — Voltage above normal range; shorted to high source.
A
CAC — Voltage below normal range; shorted to low source; open circuit.
A
RPM High — Data valid but above normal operating range; high severe
A
level.
RPM Low — Data valid but below normal operating range; high severe
A
level.
RPM Fault — Data erratic, intermittent, or incorrect.
A
RPM Fault — Mechanical system not responding correctly.
A
RPM High — Data valid but above normal operating range; least severe
W
level.
RPM Low — Data valid but below normal operating range; least severe
W
level.
The Manifold inlet temperature reached its maximum threshold limit.
A
Internal Alarms/Warnings
Description
39
