Cable arrangement

Before laying cables, check the electrical and re safety regulations applicable in
your region. Strictly follow these standards and regulations. Tips for cable
arrangement are available in

Cable routing

Before beginning the installation, we strongly advise reviewing the
placement section thoroughly. Stick to the outlined system project without
deviation. Violation of the basic KeyPad TouchScreen installation rules and the
recommendations of this manual may lead to incorrect operation, as well as
loss of connection with the device. Tips for cable routing are available in
article .
Preparing cables for connection
First, remove the insulation layer and strip the cable with a special insulation
stripper. The ends of the wires inserted into the device terminals must be tinned
or crimped with a sleeve. This ensures a reliable connection and protects the
conductor from oxidation. Tips for preparing the cables are available in
article .

Installation

Before installing KeyPad TouchScreen, make sure that you have selected the optimal
location that complies with the requirements of this manual.
To mount a keypad:
1. Turn off the power of lines in the
Hub → Settings
2. Route the cable to connect KeyPad TouchScreen to the hub casing. Connect
the wires to the required hub line.
this article .
Ajax PRO app
→ Lines → Lines Power Supply.
Device
:
this
this
