11. Terminals for connecting an external power supply unit (not included). The
terminals can be removed from the holders when necessary.
12. Input terminals for connecting the Fibra line to KeyPad TouchScreen Fibra.
13. Perforated part of the mounting panel for routing cables from the top.
14. Perforated part of the mounting panel for routing cables through the wall.
15. Perforated part of the mounting panel for routing cables from the bottom.
16. Fasteners to x the cables with ties.
Compatible hubs
Hub Hybrid (2G) or
higher is required for the keypad to operate.

Operating principle

KeyPad TouchScreen features a built-in buzzer, a touchscreen display, and a
reader for contactless authorization. The keypad can be used to control security
modes and automation devices and to notify about system events.
The keypad can automatically adjust the backlight brightness and wakes up
upon approach. Sensitivity is
interface is inherited from Ajax Security System app. There are dark and light
interface appearances to choose from. A 5-inch diagonal touchscreen display
provides access to the security mode of an object or any group and control over
automation scenarios. The display also indicates system malfunctions, if
present (when system integrity check
Depending on the settings, the KeyPad TouchScreen built-in buzzer noti es
about:
alarms;
security mode changes;
entry/exit delays;
triggering of the opening detectors.
Hub Hybrid (4G) with the rmware
adjustable
is enabled).
OS Malevich 2.21
in the app. KeyPad TouchScreen
and
