1. Fundamental of the System

1.1 Printer Overview

Front View

1
3
5
8
9
11
2
4
6
7
10
12
1.
Power on/off button
2.
Feed button
3.
Printer status LED indicator
4.
Battery status LED indicator
5.
Media cover release button
6.
Peel-off sensor (Without for linerless model)
7.
Print head
8.
Transmissive sensor – Gap sensor
9.
Media holder lock switch
10.
Media holder
11.
Media cover
12.
Reflective sensor – Black mark sensor
13.
13 Platen roller
14.
14
Tear/Peeler bar (Without for linerless model)
15 15.
Peeler module
