3.14 Replacing the Wi-Fi Module

1.
Refer to section 3.2 to remove the upper cover.
2.
Disconnect the antenna connector gently.
3.
Remove the screw and loose the spacer support on the Wi-Fi module.
4.
Replace the Wi-Fi module board.
5.
Arrange cable of antenna as indicated.
6.
Reassemble the parts in the reverse procedures.
Note:
 This is the new Wi-Fi module's replacing instruction. It should work with the main board that is -30LF version. (or later version)

If you replace the main board, please check the Wi-Fi signal band on configuration page for your using region. If any questions,
please contact the Customer Service Department of your purchased reseller or distributor for assistance.
