3.5 Replacing the Bluetooth Module
1.
Refer to section 3.2 to remove the upper cover.
2.
Remove 2 screws on the Bluetooth control board. Use a tool to remove the spacer support on the Bluetooth control board.
3.
Disconnect the connector on the board. Replace the Bluetooth module.
4.
Reassemble the parts in the reverse procedures.
20
