MAVERICK R DASHBOARD DISASSEMBLY

TOOLS NEEDED FOR INSTALLATION

- T30 Torx Driver - Phillips Screw Driver - Pry Tool
A B
A. Use a plastic pry tool to remove the driver and passenger side front
B. Remove the front fuse box cover.
trims.
C D
C. Use a plastic pry tool to remove the left and right side center panel D. Remove the left and right A pillar trims using a 3mm Allen wrench.
trims.
F
F1
E
F. Remove u-nuts from the factory panels and install on the Mav R
E. Remove the left and right side dashboard panels.
dash panels (F1).
