SSV Works MAVR-PHZ3VTD Manual page 8

G
H
G. Carefully remove the seat. H. Apply the foam pad (included in the kit) to the flat portion of the
bottom reinforcement tube.
J
I
I. Mount the brackets on the Mav R subwoofer enclosure using (4) J. Slide the Mav R subwoofer enclosure under the front seat rail
M6x12mm hex head bolts and washers. mounts and insert the brackets to the rear seat rail studs.
K
L
K. Align the front screw holes and use (2) M6x16mm hex head bolts L. Installation shown is manual was done under the driver seat,
and washer to secure the enclosure. installation under the passenger seat will have the same procedure.
8
