SSV Works MAVR-PHZ4ATD Manual

Phase 6, a-spec 5 speaker system for 2024-up can am maverick r
Hide thumbs

Advertisement

Quick Links

Download this manual
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material
or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against
defects in material or workmanship. All SSV Works and Kicker Speakers are covered by a limited
1 year warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty information.
MAVR-PHZ4ATD
2024-Up Can Am Maverick R
Phase 6, A-Spec
5 Speaker System
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAVR-PHZ4ATD and is the answer not in the manual?

Questions and answers

Related Manuals for SSV Works MAVR-PHZ4ATD

Summary of Contents for SSV Works MAVR-PHZ4ATD

  • Page 1 All SSV Works Electronics are covered by a limited 1 year warranty against installation to avoid possible injury, or defects in material or workmanship. All SSV Works and Kicker Speakers are covered by a limited damage to the accessory or vehicle.
  • Page 2 MAVERICK R DASH SPEAKER PANEL PARTS LIST PARTS LIST IMAGES Under seat 10” Subwoofer Speaker Panel Kit, Driver Side Speaker Panel Kit, Passenger Side 1650W Amplifier Assembly SSV Cage Pods with 8” Kicker Amplifier Turn-On Delay Module Horn Speakers, pair Maverick R, 800.5 Amplifier Harness [B-H3337]...

  • Page 3: Tools Needed For Installation

    MAVERICK R DASHBOARD DISASSEMBLY TOOLS NEEDED FOR INSTALLATION - T30 Torx Driver - Phillips Screw Driver - Pry Tool A. Use a plastic pry tool to remove the driver and passenger side front B. Remove the front fuse box cover. trims.
  • Page 4 MAVERICK R DASHBOARD DISASSEMBLY G. Remove the central dashboard. AMPLIFIER TURN-ON DELAY A. Connect the amplifier turn-on delay module’s power and ground B. Route the turn-on delay output wire towards the steering column. wires to the factory bus bar. Secure the module to a harness using zip ties.
  • Page 5 MAVERICK R AMPLIFIER KIT INSTALLATION TOOLS NEEDED FOR INSTALLATION - 5mm Allen Wrench The amplifiers are tuned and mounted to the bracket at the factory for ease of installation. A. The amp bracket will mount next to the power steering motor on the B.
  • Page 6 TOOLS NEEDED FOR INSTALLATION - 10mm, 13mm & 18mm Socket Wrench A. The MAVR subwoofer enclosure can be mounted under either the B. If installing the subwoofer enclosure under the driver seat, use driver or passenger side seat. an 18mm socket wrench to remove the right shoulder seat belt retractor mechanism.
  • Page 7 G. Mount the brackets on the Mav R subwoofer enclosure using (4) H. Slide the Mav R subwoofer enclosure under the front seat rail M6x12mm hex head bolts and washers. mounts and insert the brackets to the rear seat rail studs. I.
  • Page 8 C. Remove the cup holder by gently pulling up. D. Remove the center console side panels. E. Remove the screw to remove the rest of the center console side F. Run the rear speaker and subwoofer cables along the passenger panel.
  • Page 9 J. Plug in the power connector of the amps to the power cable. I. Use zip ties to tidy up the install. K. Plug in the 8-pin speaker and 2-pin subwoofer input connectors of L. Plug in the amplifier turn-on bullet connectors to the turn-on delay the amplifiers to the factory radio output wiring.
  • Page 10 O. Plug in the B-H2936 (rear speaker harness) to the B-H1913 (4-pin P. Split the B-H2936 rear speaker harness to the passenger and driver audio extension harness, 8 ft.). side along the rear firewall. Zip tie the cables to the factory harness and avoid hot or moving parts.
  • Page 11 MAVERICK R REAR CAGE POD INSTALLATION The rear cage pods are loaded with 8” Kicker Horn Speakers at the factory for ease of installation. B Pillar B Pillar SSV Logo SSV Logo A. Find the best orientation for the speaker on your bar and screw B.
  • Page 12 G. Adjust the cage pod to point towards the headrest and tighten the I. Plug in the speaker pod audio connectors to the B-H2936 rear clamp base bolts. speaker Y harnesses. MAVERICK R DASH PANEL ASSEMBLY Insert the speaker bucket grommets (included in the kit) to the A1.
  • Page 13 C. Reverse the dashboard disassembly on pages 3 and 4. D. Reinstall the center console and other panels removed during installation. Completed dash panel installation. Completed subwoofer installation under the driver seat. Completed rear speaker pods installation. E. Reinstall the seats.
  • Page 14 © 2024 SSV Works, Oxnard, CA 93030 MAVR-PHZ4ATD Rev. A 4-12-24...
